Three Phase 11kW 16A Home EV Charger 400V

Nom De Marque:	ANS
Numéro De Modèle:	EVB11B
Nombre De Pièces:	1
Détails De L'emballage:	15.7153.15 (dedans)
Conditions De Paiement:	LC, T/T, Western Union

Informations détaillées

Description de produit

Informations détaillées

Lieu d'origine:

Chine

Certification:

Nom du produit:

chargeur d'ev de la maison 11kw

Taper:

Chargeur à la maison d'EV

weiht:

Wifi:

2,5 GHz

Caractéristique clé:

Écran LCE de 2,4 pouces

Couleur du câble:

Noir ou personnalisation

Protection:

Certification:

Capacité d'approvisionnement:

100000 pièces/mois

Description de produit

3 Phase 11kw Portable Home Ev Charger With CE Certification

Product Description

The EVB11B Home Fast Charging Station revolutionizes at-home EV charging by delivering professional-grade power in a compact, user-friendly design. Engineered specifically for residential use, this 11kW charging solution can fully recharge most electric vehicles overnight, with many models achieving complete charges in just 4-6 hours - up to three times faster than standard Level 1 chargers.

Featuring intelligent power management, the EVB11B automatically adjusts charging current from 6A to 16A, preventing circuit overload while optimizing charging speed for your home's electrical capacity. The sleek control box with IP67 rating ensures reliable outdoor performance, perfectly suited for driveway or garage installation. Its 5-meter charging cable provides ample reach, while the flame-retardant, UV-resistant housing maintains integrity through years of exposure.

Smart connectivity transforms your charging experience. Through intuitive mobile app control via WiFi/Bluetooth, homeowners can schedule charging sessions during off-peak hours for maximum cost savings, monitor real-time energy consumption, and receive charging completion alerts. The 2.4-inch LCD display clearly shows charging progress, voltage, power, and accumulated energy costs. Multiple security layers, including RFID authentication and password protection, ensure that only authorized users can access the charging functions. With comprehensive safety certifications and Type B RCD protection (AC 30mA+DC 6mA), the EVB11B provides enterprise-level safety for family use, making premium home EV charging accessible and worry-free.

Core Points:

3-phase 400V input, up to 11kW output power
Type B RCD with AC/DC leakage protection
Current adjustable from 6A to 16A
IP67 rated for indoor/outdoor use

Specificaiton

Product Model EVB011B
Input/Output voltage	AC 400V
Input frequency	50/60Hz
Max.output power	3 - Phase up to 11kW(@400V 16A)
Max.output current	16A for 3 - Phase
Standard	IEC 62752:2016/COR1:2019
Certificate	CE,RoHS
Protection
Over voltage protection	Yes
Under voltage protection	Yes
Over load protection	Yes
Short circuit protection	Yes
Leakage protection	Yes
Over - temp protection	Yes
Lightning protection	Yes
Function and Accessory
LED indicators	Yes
Led screen	2.4-inch
RCD	Type B((AC 30mA+DC 6mA)
Current adjustment	Yes
Relay adhesion detection	Yes
RFID manageable	Yes
WIFI/Bluetooth	Yes(WIFI 2.4GHz)
Working environment
Protection degree	IP 67
Operation temperature	-30℃ - 55℃
Relative humidity	≤95%RH
Operating elevation limit	≤2000m
Cooling	Natural air cooling
Standby power consumption	<3W
Mechanical parameters
Charging cable	5m (Standard configuration)
Control box	H×W×D = 200mm×90mm×52mm
Weight	≤3kg
Colour	Black
Material	PC(Flame retardant, UV resistant)

Three Phase 11kW 16A Home EV Charger 400V 0

Control Box Function:

1. Leakage protection

2. Over-voltage or Low-voltage protection

3. Over-load protection

4. Lightning protection

5. Over-heat protection

6. Change current: 8A 10A 13A 16A

How to install

Three Phase 11kW 16A Home EV Charger 400V 1

Step 1: Put the wall bracket in a proper position on the wall, mark theposition of the top two screw holes on the wall using a pencil.

Step 2: Put down the wall bracket and drill the holes just marked. insertthe expansion plugs and fix the wall bracket to the wall usingself-tapping

screws.

Step 3: First insert the device into the upper mounting hole of the wallbracket. Then into the round hole of the bottom bracket andfix it on the wall bracket using combination screws.

Installation cases

Three Phase 11kW 16A Home EV Charger 400V 2

Packaging

Our Certification

Exhibition
Three Phase 11kW 16A Home EV Charger 400V 5

Visits from Various Countries (looking forward to your arrival)

Three Phase 11kW 16A Home EV Charger 400V 6
